• MPC

Metal panel mount indicator with high visibility domed lens.

  • Available in 3mm (T-1) or 5mm (T-1 ¾) flanged LED lens size.
  • Voltage input options of 5V and 12V.
  • Wire terminals or with 24AWG stripped and tinned wire leads.
  • Mounting hardware included, packed separately.
  • Range of single and multi-colors, narrow viewing angle lens appearance options.
1 - 60 of 60 | Results Per Page | View | Unit of Measure
1
Request Information Compare Items
Clear Filter

Lens Profile

  • Dome
  • Dome Diffused
  • Dome Tinted

LED Color/Wavelength

  • Amber 605nm
  • Blue 430nm
  • Green 555nm
  • Green 568nm
  • Red 625nm
  • Red 625nm/Green 568nm
  • Red 645nm
  • Red 700nm
  • Yellow 590nm

Termination

  • No Wires
  • Wires Stripped/Tinned
  • Wires Stripped/Tinned .100 Connector

Wire Length (in)

  • 4
  • 6
  • 6.5
  • 8
  • 12
  • 12.5
  • 18
  • 35

Item #


3D Model

Lens Profile

Housing Material

LED Color/Wavelength

Termination

Panel Cutout

Wire Length

Stock

MPC3AD
MPC3AD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Amber 605nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3ADW12.0
MPC3ADW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Amber 605nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC3BC
MPC3BC
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm/Green 568nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3BCW6.0
MPC3BCW6-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm/Green 568nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC3BWD
MPC3BWD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Blue 430nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3BWDW12.0
MPC3BWDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Blue 430nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC3GD
MPC3GD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 568nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3GDL
MPC3GDL
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 568nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3GDW12.0
MPC3GDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 568nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC3GDW6.0
MPC3GDW6-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 568nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC3HD
MPC3HD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3HDL
MPC3HDL
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3HDW12.0
MPC3HDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC3HDW6.0
MPC3HDW6-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC3RD
MPC3RD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 700nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3RDW12.0
MPC3RDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 700nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC3SRD
MPC3SRD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 645nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3SRDW6.0
MPC3SRDW6-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 645nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC3YD
MPC3YD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Yellow 590nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3YDW12.0
MPC3YDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Yellow 590nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC3YT
MPC3YT
 		N/A CAD Icon (for items table) N/A Dome Tinted N/A Metal N/A Yellow 590nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC3YTW12.0
MPC3YTW12-0
 		N/A CAD Icon (for items table) N/A Dome Tinted N/A Metal N/A Yellow 590nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC3YTW6.0
MPC3YTW6-0
 		N/A CAD Icon (for items table) N/A Dome Tinted N/A Metal N/A Yellow 590nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC5AD
MPC5AD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Amber 605nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5ADW12.0
MPC5ADW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Amber 605nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC5ADW6.0
MPC5ADW6-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Amber 605nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC5BC
MPC5BC
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm/Green 568nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5BCW12.5
MPC5BCW12-5
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm/Green 568nm N/A Wires Stripped/Tinned N/A Round N/A 12.5 in N/A
CHECK STOCK
MPC5BCW18.0
MPC5BCW18-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm/Green 568nm N/A Wires Stripped/Tinned N/A Round N/A 18 in N/A
CHECK STOCK
MPC5BCW35.0
MPC5BCW35-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm/Green 568nm N/A Wires Stripped/Tinned N/A Round N/A 35 in N/A
CHECK STOCK
MPC5BCW6.0
MPC5BCW6-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm/Green 568nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC5BWD
MPC5BWD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Blue 430nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5BWDW12.0
MPC5BWDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Blue 430nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC5BWDW12.0-CC
MPC5BWDW12-0-CC
 		N/A CAD Icon (for items table) N/A Dome N/A Metal N/A Blue 430nm N/A Wires Stripped/Tinned .100 Connector N/A Round N/A 12 in N/A
CHECK STOCK
MPC5GD
MPC5GD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 555nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5GD24VW6-ER
MPC5GD24VW6-ER
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 568nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC5GDW12.0
MPC5GDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 555nm N/A Wires Stripped/Tinned N/A Round N/A N/A
CHECK STOCK
MPC5GDW12.5
MPC5GDW12-5
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 555nm N/A Wires Stripped/Tinned N/A Round N/A 12.5 in N/A
CHECK STOCK
MPC5GDW6.0
MPC5GDW6-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 555nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC5GDW6.5
MPC5GDW6-5
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 555nm N/A Wires Stripped/Tinned N/A Round N/A 6.5 in N/A
CHECK STOCK
MPC5GDW8.0
MPC5GDW8-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 555nm N/A Wires Stripped/Tinned N/A Round N/A 8 in N/A
CHECK STOCK
MPC5GDW8.0-CC
MPC5GDW8-0-CC
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Green 555nm N/A Wires Stripped/Tinned .100 Connector N/A Round N/A 8 in N/A
CHECK STOCK
MPC5GT
MPC5GT
 		N/A CAD Icon (for items table) N/A Dome Tinted N/A Metal N/A Green 568nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5GTW12.0
MPC5GTW12-0
 		N/A CAD Icon (for items table) N/A Dome Tinted N/A Metal N/A Green 568nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC5HD
MPC5HD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5HDW12.0
MPC5HDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC5HDW4.0
MPC5HDW4-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A Wires Stripped/Tinned N/A Round N/A 4 in N/A
CHECK STOCK
MPC5HDW6.0
MPC5HDW6-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A Wires Stripped/Tinned N/A Round N/A 6 in N/A
CHECK STOCK
MPC5HDW6.0-CC
MPC5HDW6-0-CC
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A Wires Stripped/Tinned .100 Connector N/A Round N/A 6 in N/A
CHECK STOCK
MPC5HDW8.0
MPC5HDW8-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A Wires Stripped/Tinned N/A Round N/A 8 in N/A
CHECK STOCK
MPC5HDW8.0-CC
MPC5HDW8-0-CC
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 625nm N/A Wires Stripped/Tinned .100 Connector N/A Round N/A 8 in N/A
CHECK STOCK
MPC5HT
MPC5HT
 		N/A CAD Icon (for items table) N/A Dome Tinted N/A Metal N/A Red 625nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5HTW12.0
MPC5HTW12-0
 		N/A CAD Icon (for items table) N/A Dome Tinted N/A Metal N/A Red 625nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC5RD
MPC5RD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 700nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5RDW12.0
MPC5RDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Red 700nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC5SRCW6.5
MPC5SRCW6-5
 		N/A CAD Icon (for items table) N/A Dome N/A Metal N/A Red 645nm N/A Wires Stripped/Tinned N/A Round N/A 6.5 in N/A
CHECK STOCK
MPC5YD
MPC5YD
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Yellow 590nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5YDW12.0
MPC5YDW12-0
 		N/A CAD Icon (for items table) N/A Dome Diffused N/A Metal N/A Yellow 590nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
MPC5YT
MPC5YT
 		N/A CAD Icon (for items table) N/A Dome Tinted N/A Metal N/A Yellow 590nm N/A No Wires N/A Round N/A N/A
CHECK STOCK
MPC5YTW12.0
MPC5YTW12-0
 		N/A CAD Icon (for items table) N/A Dome Tinted N/A Metal N/A Yellow 590nm N/A Wires Stripped/Tinned N/A Round N/A 12 in N/A
CHECK STOCK
